Wire Straightening & Cutting Machine
We are famous for manufacturing good quality wire straightening and cutting machine. Our robustly built machines are not only long lasting but are also help in enhancing productivity besides being energy efficient.
Wire Straightening & Cutting Machine
Specifications of Wire Straightening and Cutting Machine |
||||
| Model | Thickness of Wire (mm/inches) | Cutting Capacity Per min. | Length of Wire to be cut Automatically | Power Required H.P/R.P.M |
| True-01 S | 1.6 - 5/ 0.062-0.192 |
70 ft. | 25 - 1000 mm 1 - 36 inches |
2 x 1440 |
| True-02 S | 2-7/ 0.080-0.250 |
60 ft. | 25 - 1000 mm 1 - 36 inches |
3 x 1440 |
| True-03 S | 3.2-8/ 0.125-0.315 |
55 ft. | 25 - 1000 mm 1 - 36 inches |
5 x 1440 |
| True-04 S | 3.2-10/ 0.125-0.375 |
50 ft. | 25 - 1000 mm 1 - 36 inches |
5 x 1440 |
| True-05 S | 3.2-12.7/ 0.125-0.5 |
45 ft. | 50 - 1200 mm 2 - 48 inches |
10 x 1440 and 2 x 1440 |
| True-06 S | 8-15/ 0.315-0.590 |
40 ft. | 75 - 1800 mm 3 - 72 inches |
10 x 1440 and 3 x 1440 |
Measurements, Design, Output & Weight etc. are subject to change without notice
